FDA Approved
Preset exposure dose
300+ exposures on a full charge
Docking station
Secure strap
Dual Protection
The safety of users is our priority. The XVbeam2000 features a dual-protection design.
External Backscatter Shielding
Disperse radiation occurs when the beam interacts with the patient's surface, causing radiation residuals to scatter. The backscatter shield significantly minimizes the operator's radiation dose.
Internal Protection
The internal radiation shielding is optimally constructed to shield the operator from radiation leakage
The voltage and current of 65Kv and 2.6mA generate more power to penetrate the teeth and obtain clear images.
The focal spot size of 0.4mm significantly focuses more x-rays
on the target teeth and produces a higher quality image on film or sensor.
| Specifications | XVbeam 2000 |
|---|---|
| Focal Spot | 0.4 mm |
| Tube Voltage (kV) | 65 kV |
| Tube Current (mA) | 2.6 mA |
| Exposure Time Range | 0.01~2 sec |
| Inherent filtration | 0.8 mmAl |
| Additional Filtration | 1.0 mmAl |
| Source to Skin Distance | 200 mm |
| X-ray Field | φ60 mm |
| Power Input | 22.2 V |
| Weight | 2.1KG |
